R7
Rolansini
ROLANSINI R7 outward-opening casement window addresses the challenges of wind pressure resistance and waterproofing in high-rise residential buildings through its 1.8mm wall thickness and six-layer sealing technology, while its 29mm thermal break strip and 27A double-glazed windows solve the problems of heat insulation and soundproofing. It is particularly suitable for buildings near roads, high-rise buildings, or coastal areas that are humid, rainy, and prone to typhoons.
R7 Aluminum Thermal Break Outswing Casement Window is distinguished by a set of key strengths that set it apart in the market:
· Superior Energy Efficiency: Equipped with a 6-chamber sealing system and foam-filled insulation zone, it minimizes heat transfer, reducing reliance on heating or cooling systems. This not only lowers energy bills but also aligns with global sustainability standards.
· Enhanced Security: Integrating premium hardware from German brands like SIEGENIA, HOPPE, and WEHAG (180°), the window features a multi-point locking system with 4-point reinforcement (main lock + middle lock on the hinge side), providing robust anti-pry protection.
· Weather Resistance: Designed to withstand extreme conditions, its structure includes a 125mm thermal break aluminum frame and 29mm thermal break strips, paired with a 6-layer sealing system using EPDM rubber strips. This ensures airtight and watertight performance, ideal for stormy or humid climates.
· Customization Flexibility: From finishes to glass types, the R7 window adapts to diverse design needs. Choose from powder coating, PVDF coating, or wood grain transfer for finishes, and select from double/triple panes, low-e, laminated, or frosted glass to match aesthetic and functional requirements.
Specification | Details |
Profile Reinforcement | 1.8mm |
Finish Treatment | Powder Coating, PVDF Coating, Wood Grain Transfer |
Frame Depth | 70mm (Single system), 125mm (Integrated system) |
Frame Width | 53.2mm |
Sash Width | 83.6mm |
Max. Leaf Dimensions | Width: 370-800mm; Height: 460-1700mm |
Glass Standard | 37mm (5G + 27A + 5G) Double Toughened Clear Glass (Argon Gas-filled) |
Glass Types Available | Double Panes, Triple Panes, Clear, Ultra Clear, Low-e, Laminated, Reflective, Frosted |
Screens | 304 / 316 Stainless Steel, Foldable Nylon Mesh Screen |
Blinds Option | HANS Manual Blinds, Electric Blinds, Solar Powered Built-in Blinds |
Opening Types | Outswing, Outswing & Awning |
Certifications | ISO9001, CE, NFRC, AS2047, CSA |
Warranty | 10 Years (Terms and conditions apply) |
The 125mm wall-covering broken bridge aluminum frame forms the backbone of the R7 window, ensuring structural rigidity. Combined with 29mm thermal break strips, it not only enhances insulation but also boosts wind resistance. For high-wind areas, optional reinforced profiles with steel inserts in the middle mullion provide extra strength, making it a reliable choice for hurricane zones.
A 6-layer sealing system (3 between sash and frame, 3 between frame and outer frame) uses EPDM rubber strips and composite foam to block drafts, rain, and heat. Complementing this, a hidden drainage system channels water away without visible outlets, preserving the window’s sleek appearance while preventing indoor leaks.
Beyond the multi-point locking system, the R7 window offers additional security layers: 304/316 stainless steel mesh screens and removable metal guardrails (fixed or active). These features deter unauthorized access without compromising ventilation.
The outward-opening design maximizes airflow, while a standard anti-fall chain prevents accidental detachment during storms. A built-in “rest block” reduces stress on hardware, extending its lifespan. Optional safety limiters control opening angles, enabling micro-ventilation and child-safe operation, supported by smooth-functioning SI friction hinges.
