H5
Rolansini
The H5 ROTO Airtight Compression Aluminum Sliding Window stands as a breakthrough in window engineering, crafted by Rolansini to address long-standing challenges in traditional sliding and casement windows. Unlike conventional designs, this window integrates a squeeze-type closing mechanism that eliminates poor sealing issues common in sliding windows while avoiding the space-consuming drawbacks of casement styles.
At its core, the H5 ROTO window achieves superior airtightness through a precision-engineered system: the sash and frame press tightly together, reinforced by three layers of sealing strips around both components. Paired with a customized hardware setup, this design ensures a secure, weather-resistant seal—making it ideal for diverse climates, from humid regions to areas prone to strong winds.
Beyond functionality, the H5 Airtight Compression Aluminum Sliding Window window prioritizes user needs with cost-effectiveness, space efficiency, and an unobstructed view. Its low-maintenance design reduces long-term upkeep, while adjustable ventilation control lets you balance airflow and insulation effortlessly. Whether for residential homes, modern offices, or commercial buildings, this window blends performance with aesthetic appeal.
Specification | Details |
Profile Reinforcement | 1.8mm |
Finish Treatment | Powder Coating, PVDF Coating, Wood Grain Transfer |
Frame Depth | 118mm |
Frame Width | 64mm |
Sash Width | 81.8mm (bottom), 58.3mm (upper) |
Max. Leaf Width | 700-1200mm (Active Pane), 400-4200mm (Fixed Pane) |
Max. Leaf Height | 1800-2700mm (Active Pane), 400-4200mm (Fixed Pane) |
Glass Standard | 30mm (5G+20A+5G) Double Toughened Clear Glass, Filled with Argon Gas |
Glazing Pocket | Less than 36 mm |
Glass Spacer | Black Aluminum Spacer |
Glass Type | Double Panes, Clear, Ultra Clear, Low-e, Laminated, Reflective, Frosted |
Hardware | German ROTO Compression Hardware |
Screens | 304/ 316 Stainless Steel Mesh Screens, Foldable Nylon Mesh Screen |
Blinds | HANS Manual Blinds, Solar Powered Built-in Blinds |
Standard | Comply with ISO9001, CE, NFRC, AS2047, CSA Certification |
Warranty | 10 Years - Terms and conditions apply |
At the heart of the H5 ROTO window is its German ROTO Compression Hardware—a imported system that delivers smooth, silent operation even with heavy loads (up to 200kg per sash). The aluminum alloy handle resists corrosion, ensuring longevity in harsh environments, while a multi-point locking mechanism enhances security. Angled drainage channels further reinforce its durability, efficiently expelling water during typhoons or heavy rains—making it a reliable choice for storm-prone areas.
The H5 ROTO window redefines spatial aesthetics with its slim-frame design. By reducing the visible indoor frame width by 20%, it creates a near-seamless transition between indoor and outdoor spaces, perfect for enjoying panoramic views. Structural reinforcements allow for oversized glass panels (up to 3m²), while optional 82mm-high waterproof rails and built-in safety glass barriers blend security with modern design—no need to sacrifice style for protection.
Security meets convenience with the innovative quadruple-eight locking mechanism, which secures the window across four sides. This design not only boosts burglary resistance but also enhances airtightness: combined with continuous sealing strips, it prevents air and water infiltration, even in extreme weather. Despite its robust security, the window retains the effortless push-pull operation of traditional sliding windows—no cumbersome handles or complicated locks.
The H5 ROTO window adapts to your unique style and requirements with a range of customization options. Choose from 8 finish options (7 solid colors + woodgrain) to match your architecture, whether modern, minimalist, or European. Multifunctional combinations—including sliding panels, retractable screens, and glass railings—add versatility, while practical accessories like anti-collision pedals, reinforced glass supports, and open drainage covers address everyday needs: insect prevention, child safety, and easy maintenance.
Beyond its technical specs, the H5 ROTO window stands out for its ability to balance form and function. It meets global standards (ISO9001, CE, etc.), ensuring quality you can verify, and backed by a 10-year warranty, it offers long-term peace of mind. Whether you’re renovating a home, designing a new building, or upgrading for energy efficiency, this window delivers: airtightness to reduce energy costs, space efficiency for smaller rooms, and a sleek design that elevates any space.
